MAXPULSE MAXDIM

MAXPULSE "B"

Part No: 9200-000-B

$255.00
Shipping calculated at checkout.
DESCRIPTION

MaxPulse "B" Model



Features:

  • Aircraft Landing Light Pulser, Wig Wag control
  • No outboard heat sinks, rheostats, or other packages
  • STC, PMA,  RTCA/DO-160E SEC 21:  qualified
  • Configure for Wig Wag or Wing and taxi light pulsing, single
  • light pulsing etc.
  • Increased safety for your passengers and yourself
  • Hundreds of DC Lighting Applications
  • Emergency Vehicles
  • Assembled in the USA

Specifications:

  • Voltage Range: 12 to 35VDC
  • Warm-up cycle prior to pulsing
  • Two Channels
  • MaxPulse Function Modes: Switch Positions
    •  X Both Circuits Off
    •  S Starboard (right) on only
    •  P Port (left) on only
    •  S+P Both circuits On
    •  A44 Alternate 44 PPM (STD)
    •  B44 Both Flash 44 PPM
    •  A88 Alternate 88 PPM
    •  A120 Alternate 120 PPM
  • Operating Temperature Range: -30 degrees C to +65 degrees C
  • Internal Temperature Protect: +85 degrees
  • Storage Temperature: -40 degrees C to +100 degrees C
  • Maximum Internal Temperature: @10 A +25 degrees C above Ambient.
  • Enclosure Material: Bayer FR110 resin Meets UL 94
  • Flame Rating: V-2 (0.03in) V-0 (0.059in) 5VB (0.098in) 5VA (0.13in)
  • FAA STC/PMA Approved
  • RTCA/DO-160E Qualified
  • One Year limited warranty
  • Weight: 1oz (28g)
  • What's in the box? MaxPulse unit, installation instructions, color coded terminals, reference panel label, STC printout for your logs, installation template, and knob.
Ring lug unit similar dimensions

1.6 inches square
