Evolution 1000 MFD

Part No:

Manufacturer: ASPEN AVIONICS

The EFD1000 MFD is designed to enhance your choice of Evolution primary flight display, adding moving maps, datalink weather and traffic interfaces, a built-in terrain awareness database, flight information pages and more. Built using the same hardware as your PFD, this EFD1000 MFD gives you a full duplicate set of ADAHRS sensors, works with your PFD to continually monitor its health, and can automatically become a backup PFD if your primary should fail.


  • Duplicate sensor set providing full PFD redundancy
  • May eliminate requirement for backup instruments
  • Sectional-style moving maps with hazard awareness overlays
  • Charts and geo-referenced airport diagrams(1)
  • Customizable screen layouts
  • Built-in backup battery and emergency GPS(2)

Evolution Hazard Awareness

  • Built-in terrain awareness
  • Traffic overlay on map via interface(3)

Weather

  • WX500 Stormscope interface
  • Datalink weather(4)
  • Hi-res NEXRAD radar
  • AIRMETs
  • Radar coverage map
  • SIGMETs
  • Precipitation type (at surface) TFRs
  • Echo tops Storm weather tracks
  • Cloud tops Lightning
  • Winds aloft (by altitude) METARs
  • Satellite mosaic (by altitude)
  • TAFs

General Specifications:

Overall Dimensions:   3.50” W x 7.00”H x 4.15”D
Weight:  2.9 lbs. with mounting bracket
Display Type:   6.0” Diagonal TFT Active Matrix LCD
Display Resolution:   400x760
Display Backlight:   High Intensity White LED
Display Colors:   32,768

Operational Specifications:

Operating Temp   -20°C to +55°C
Storage Temp   -55°C to +85°C
Max Operating Altitude (unpress.)   35,000 ft.
Cooling   Integral Fan
Max Humidity   95% at 50°C
Input Voltage   +8 to +32 Volts DC
Max Current   2.4 Amps @ 28 Vdc  /  4.8 Amps @ 14 Vdc

I/O Specifications:

ARINC 429 Inputs   5 Low Speed
ARINC 429 Outputs   1 Low Speed
RS-232 Inputs   5
RS-232 Outputs   3
Pitot / Static   Quick Connect

Certification Specifications:

FAA and EASA Technical Standard Orders
TSO/ETSO: C2D, C3D, C4C, C6D, C8D, C10B, C106, C113

Software
RTCA DO-178B Level C

Environmental
RTCA DO-160E



See below for answers to our most popular questions.

Have a Question?

  • AOA update available ?

    The AOA unlock feature is available. Price is $525, plus the labor required for installation and setup. This may require a test flight to complete.

    Give us a call at (863) 709-9714 and extension 112 to discus further.

  • Does 1000 MFD have to be installed by you or can I purchase and have my avionics installer do it?

    Aspen requires that their systems be installed by an Aspen dealer.
