GARMIN
Oil/Fuel Pressure Sensor, 150PSIG (Stainless Steel)
Part No: 494-30032-00
$1,305.00
/
Shipping calculated at checkout.
DESCRIPTION
Function: Oil Pressure Transducer
Operating Temperature Range: -55 °C to +150 °C (-67 °F to +302 °F)
Gage Range: 0 to 150 psig
Accuracy: ± 3%
Resistance: Rin > 1000 Ω, Rout < 2000 Ω
Output Voltage Range: 0 to 50 mV
Material: Stainless Steel
Weight: 0.3 lb
Thread:7/16-20UNJF-3A
Mount Type: Screw-in
NOTES
Typical power consumption 100 mW.
Mounting torque ≤75 in-lb.
Operating altitude up to 51,000 feet.
Proof Pressure 300 psig.
Burst Pressure 450 psig.
