Garmin
Fuel Flow Transducer FT-60 (Red - Up to 350HP)
Part No: 494-10001-00
$450.00
/
Shipping calculated at checkout.
DESCRIPTION
Function: Fuel Flow Transducer
Engine Type: 0 to 350 HP
Operating Temperature Range: -65 °C to +125 °C (-85 °F to +257 °F)
Gage Range: 0.6 to 70+ GPH
Accuracy: Linearity ± 1%, Repeatability ± .25%
Weight: 5.26 oz (0.32875 lb)
Thread: 1/4”
Port: Female NPT
Size: 1.90” x 1.375” x 1.62”
K-Factor: 68,000 pulses/gallon
Pressure Drop: 0.5 psi at 28 GPH / 2.0 psi at 56 GPH
NOTES
Working pressure 250 psi.
Minimum burst pressure 4000 psi.
Life expectancy 10,000 hour minimum
